BT Prime Mover OPX30 Order Picker Truck Manual

Order Picker Truck Model: Prime Mover OPX30
Publication 311348-000
English 2003
Format: PDF

BT Prime Mover OPX30 Order Picker Truck Service Manual: 570 Pages

Order Picker Truck Manual Table of Content:

0 Chassis
1 Motors
2 Drive Gear / Transmission
3 Brake / Wheel System
4 Steering System
5 Electrical System
6 Hydraulic / Pneumatic System
7 Operating Function-lifting Mast / Cylinders
8 Peripheral / Installation Equipment

Electronic circuit boards and devices used on the truck can be damaged by the discharge of static electricity, called electrostatic discharge.

Static charges can accumulate from normal operation of the truck as well as movement or contact between nonconductive materials such as, plastic bags, synthetic clothing, synthetic soles on shoes, styrofoam coffee cups, etc.
Accumulated static can be discharged through human skin to a circuit board or component by touching the parts. Static discharge is also possible through the air when a charged object is placed close to another surface at a different electrical potential. Static discharge can occur without your seeing or feeling it.

Whenever working on or near static-sensitive electronics, always use static discharge precautions.

1. Static-sensitive items are to remain in their protective containers except when actually in use at the static-free station.
2. Before removing the item(s) from their protective container, the operator should place the container on the conductive grounded bench top. Make sure the wrist strap fits snugly around the wrist and is properly plugged in/attached to the ESD ground plug on the truck. The operator should then touch hands to the conductive bench top, workstation, or truck.
3. All operations on the items should be performed with the items in contact with the truck or grounded bench top.
4. Do not allow conductive magazine (static-sensitive items) to touch hard-grounded test gear or bench top.
5. Ordinary plastic solder-suckers and other plastic assembly aids should not be used.
