Case 325 Articulated Truck Service Manual

Table of Contents

• Content
• Maintenance
• General Instructions
• Engine
• Transmission
• Front Axle
• Rear Axle
• Brakes System
• Hydraulic System
• Steering
• Wheels
• Electrical System
• Cab and Chassis

Manual Extract: Input Shaft

1. Heat the gear to about 120 °C (248 °F) and assemble until contact is obtained.

2. Install the gear with the snap ring.

3. Install the snap ring into the recess of the turbine shaft.

4. Install the turbine shaft until the snap ring snaps into the recess of the input shaft.
