Case CX220C Crawler Excavator Service Manual

Table of Contents

1. Content
2. Introduction
3. Engine
4. Hydraulics System
5. Frames and Ballasting
6. Tracks and Track Suspension
7. Cab Climate Control
8. Electrical System
9. Booms, dippers and buckets
10. Platform, cab, bodywork and decals
11. Special Tools Index

Manual Extract: Exhaust muffler – Remove

1. Remove cover (1).
2. Remove 8 nuts (2) M8 and 2 U-bolts (3).: 13 mm
3. Remove 2 sems bolts (4) M10 X 35, 2 washers (5) and 2 nuts (6).: 17 mm
4. Separate clamp assembly (7) from muffler (8).
5. Remove muffler (8).
Weight: 18 kg (40 lb)
