Case CX470B Crawler Excavator Service Manual
$35.00
What’s Included
| Service Manual | 1,509 Pages |
|---|
Technical Details
| Brand | Case |
|---|---|
| Model Covered | CX470B |
| Machine Type | Excavator |
| Documentation | Service Manual |
| Publication Numbers | 48004716 (Mar 2016) |
| Language | English |
| Format |
Table of Contents
- General Information
- Engine
- Fuel System
- Frames and ballasting
- Electrical systems
- Undercarriage
- Drive Train
- Upper structure Hydraulics
- Upper structure
Manual Extract: Minimum flow adjustment
Loosen the hexagon nut (808) and tighten (or loosen) the hexagon socket head locking screw (953) to adjust the flow control characteristic. Similar to the maximum flow adjustment, this does not change other control characteristic. However, if the hexagon socket head locking screw is tightened too much, the required power may increase at the time of maximum discharge pressure (during relief), so adjust this carefully.
