Liebherr L507S, L509S, L514 Wheel Loader Manual

Wheel Loader Applicable Model :
L 507 S from serial 9099 (Type 787)
L 509 S  from serial 9099 (Type 789)
L 514 from serial 14000 (Type 790)

Language: English
Publication: 1028 8197
Format: PDF

Liebherr L507S, L509S, L514 Wheel Loader Service Manual – 600 Pages
Operating manual – 274 Pages

Table of Content of the Service Manual:

• General information
• Product description
• Maintenance
• Diesel engine
• Cooling system
• Travel hydraulics
• Working hydraulics
• Steering system
• Brake system
• Electrical system
• Transfer gear
• Axles, drive shafts
• Machine frame, ballast weight
• Central lubrication system
• Covering, cab access
• Cab, heating, air-conditioning
• Lift arm, quick-change device
• Attachments, accessories
• Repair work, troubleshooting
• Options

This manual has been issued to provide you with technical information on design, function, disassembly, assembly, adjustments and troubleshooting of components and assemblies on the LIEBHERR wheel loader.

This manual describes a variety of types and finished forms. In general, this information applies to the types and serial number groups specified in the footnotes. One exception is that specific type and serial number data are indicated at the beginning of each section (e.g. the technical specifications of the components).

It is imperative that safety regulations be observed with all tasks done on the machine. You will find information on this in the General Information chapter. Whenever possible, parts and components are supplemented by indication of the identification number in the heading.
