Tigercat S860C, LS870C Shovel Logger Repair Service Manual
$36.00
What’s Included
| Tigercat S860C, LS870C Shovel Logger Repair Service Manual (Issue 1.0, October 2008) | 376 Pages |
|---|---|
| Tigercat S860C, LS870C Shovel Logger Operators Manual (Issue 1.0, October 2008) | 164 Pages |
Technical Details
| Brand | Tigercat |
|---|---|
| Serial Numbers | S860C: 86051501 TO 86052499; LS870C: 87001501 TO 87002499 |
| Language | English |
| Format | |
| Serial / PIN Range Details | S860C: 86051501 TO 86052499; LS870C: 87001501 TO 87002499 |
| Original Manual Coverage | Tigercat S860C, LS870C Shovel Logger Repair Service Manual – 376 Pages |
| Machine Type | Tigercat Shovel Logger |
| Publication Numbers | Issue 1.0, October 2008 |
| Models Covered | S860C, LS870C Shovel Logger |
Tigercat S860C, LS870C Shovel Logger Repair Service Manual
Machine Type: Tigercat Shovel Logger
Language: English
Format: PDF
Publication: Issue 1.0, October 2008
Serial Number:
S860C: 86051501 TO 86052499
LS870C: 87001501 TO 87002499
- Tigercat S860C, LS870C Shovel Logger Repair Service Manual – 376 Pages
- Tigercat S860C, LS870C Shovel Logger Operators Manual – 164 Pages
Table of Content of Tigercat S860C, LS870C Manual
INTRODUCTION………………………………………………………………………………………………… ii
STANDARDS, TOPS, FOPS, OPS ………………………………………………………………………. iv
NON-APPROVED FIELD PRODUCT CHANGES …………………………………………………… v
SAFETY …………………………………………………………………………………………………………….1
CONTROLS AND OPERATION ……………………… See separate OPERATOR’S MANUAL
LUBRICATION AND MAINTENANCE ……………………………………………………………………3
HYDRAULIC SYSTEM/ LOAD SENSE CONTROL ………………………………………………….4
PILOT SYSTEM ………………………………………………………………………………………………….5
ELECTRICAL AND COMPUTERS…………………………………………………………………………6
ENGINE START AND STOP ………………………………………………………………………………..7
ENGINE ANTI-STALL ………………………………………………………………………………………….9
OIL COOLER/RADIATOR AND COOLING FAN …………………………………………………… 10
TRACK DRIVE …………………………………………………………………………………………………. 11
BOOM FUNCTIONS …………………………………………………………………………………………. 12
LEVELLING……………………………………………………………………………………………………… 13
SWING……………………………………………………………………………………………………………. 15
GRAPPLE ………………………………………………………………………………………………………..17
MISCELLANEOUS ……………………………………………………………………………………………. 25
The S860C, LS870C Shovel Logger is designed for log transferring, loading, and shovel logging (hoechucking) by swinging logs closer to the road side minimizing ground surface impact and damage.
| Serial | 1. Publication: Issue 2.3, March 2020, 2. Publication: Issue 1.0, March 2023 |
|---|
