Case CX15B, CX18B Series 2 Mini Excavator Service Manual
$34.00
What’s Included
| Service Manual | 879 Pages |
|---|
Technical Details
| Brand | New Holland |
|---|---|
| Model Covered | CX15B, CX18B Series 2 |
| Machine Type | Mini Excavator |
| Documentation | Service Manual |
| Publication Numbers | 84533370B (May 2014) |
| Publication Year | 2014 |
| Language | English |
| Format |
Table of Contents
- Content
- Introduction
- Engine
- Hydraulics System
- Frames and Ballasting
- Tracks and Track Suspension
- Electrical System
- Booms, dippers and buckets
- Dozer Blade and Arm
- Platform, cab, bodywork and decals
Manual Extract: Cylinder head – Assemble
Installation of cylinder head gasket
NOTE: Do not use liquid gasket.
1. Make sure that there is no dirt or dents on the top surfaces of the cylinder block and pistons.
2. Screw in two guide bolts in the bolt holes of the block.
3. Place the new cylinder head gasket on the cylinder block using the guide bolts as a guide.
NOTE: The model name is stamped on the front top face of the gasket so that it is not confused with one for other model.
Installation of cylinder head assembly Install the cylinder head by means of the guide screws
