Case CX17C Mini Excavator Service Manual

Table of Contents

1. Content
2. Introduction
3. Engine
4. Hydraulics System
5. Frames and Ballasting
6. Tracks and Track Suspension
7. Electrical System
8. Booms, dippers and buckets
9. Dozer Blade and Arm
10. Platform, cab, bodywork and decals
11. Special Tools Index
12. Electrical Schematic
13. Hydraulic Schematic

Manual Extract: Camshaft alignment

1. Support the camshaft with V blocks on the surface plate at both end journals.
2. Set a dial indicator with its tip on the intermediate journal.
3. Measure the camshaft alignment.
4. If the measurement exceeds the allowable limit, replace the camshaft.

Camshaft alignment
Allowable limit: 0.01 mm (0.0004 in) SMIL17MEX0580AB 4
Cam height
1. Measure the height of the cam at its highest point with an outside micrometer.
2. If the measurement is less than the allowable limit, replace the camshaft.
Cam height (intake and exhaust) Factory specification: 26.88 mm (1.058 in) Allowable limit: 26.83 mm (1.056 in)
