Case Farmall 80N, 90N, 100N, 110N Tractor Service Manual

Table of Contents

1. Introduction
2. Engine
3. Clutch
4. Transmission
5. Four Wheel Drive
6. Front Axle
7. Rear Axle
8. Power Take Off
9. Brake and Controls
10. Hydraulic Systems
11. Hitches, Drawbars and implement couplings
12. Frames and ballasting
13. Steering
14. Wheels
15. Cab Climate Control
16. Electrical System
17. Platform, cab, bodywork and decals
18. Special Tools

Manual Extract: Diesel Particulate Filters (DPF) – Install – Protective grill

1. Recover and thoroughly clean the particulate filter (DPF)protective grill (1) and store it in a suitable place.

2. Correctly position the protective grill (1) on the particulate filter (DPF).

3. Tighten the two retaining screws (1) on the rear face of the particulate filter (DPF) protective grill (2).

4. Tighten the two retaining screws (1) on the front face of the particulate filter (DPF) protective grill (2).

5. Tighten the upper retaining screw (1) on the upper front face of the particulate filter protective grill (DPF).
