Tigercat S855C, LS855C Shovel Logger Repair Service Manual
Price range: $36.00 through $40.00
Machine Type: Tigercat Shovel Logger
Language: English
Format: PDF
1. Publication: Issue 2.1, February 2012
Serial Number:
S855C: 85550101 TO 85551000
LS855C: 85500101 TO 85501000
- Tigercat S855C, LS855C Shovel Logger Repair Service Manual – 436 Pages
- Tigercat S855C, LS855C Shovel Logger Operators Manual – 186 Pages
2. Publication: Issue 1.1, July 2015
Serial Number:
S855C: 85551001 TO 85552000
LS855C: 85501001 TO 85502000
- Tigercat S855C, LS855C Shovel Logger Repair Service Manual – 612 Pages
- Tigercat S855C, LS855C Shovel Logger Operators Manual – 266 Pages
Tigercat S855C, LS855C Shovel Logger Repair Service Manual
Machine Type: Tigercat Shovel Logger
Language: English
Format: PDF
1. Publication: Issue 2.1, February 2012
Serial Number:
S855C: 85550101 TO 85551000
LS855C: 85500101 TO 85501000
- Tigercat S855C, LS855C Shovel Logger Repair Service Manual – 436 Pages
- Tigercat S855C, LS855C Shovel Logger Operators Manual – 186 Pages
2. Publication: Issue 1.1, July 2015
Serial Number:
S855C: 85551001 TO 85552000
LS855C: 85501001 TO 85502000
- Tigercat S855C, LS855C Shovel Logger Repair Service Manual – 612 Pages
- Tigercat S855C, LS855C Shovel Logger Operators Manual – 266 Pages
Table of Content of Tigercat S855C, LS855C Manual
INTRODUCTION…………………………………………………………………………………………………………………… v
STANDARDS, ROPS, TOPS, FOPS AND OPS………………………………………………………………………….vi
NON-APPROVED FIELD PRODUCT CHANGES………………………………………………………………………vii
SAFETY……………………………………………………………………………………………………………………………….. 1
CONTROLS AND OPERATION…………………………………………..See separate OPERATOR’S MANUAL
LUBRICATION AND MAINTENANCE………………………………………………………………………………………. 3
HYDRAULIC SYSTEM/ LOAD SENSE CONTROL……………………………………………………………………. 4
PILOT SYSTEM……………………………………………………………………………………………………………………. 5
ELECTRICAL AND COMPUTERS…………………………………………………………………………………………… 6
ENGINE ………………………………………………………………………………………………………………………………. 7
OIL COOLER/RADIATOR AND COOLING FAN………………………………………………………………………. 10
TRACK DRIVE……………………………………………………………………………………………………………………. 11
BOOM FUNCTIONS…………………………………………………………………………………………………………….. 12
LEVELING………………………………………………………………………………………………………………………….. 13
SWING………………………………………………………………………………………………………………………………. 15
GRAPPLE …………………………………………………………………………………………………………………………. 17
HEEL…………………………………………………………………………………………………………………………………. 18
BAR SAW…………………………………………………………………………………………………………………………… 22
MISCELLANEOUS………………………………………………………………………………………………………………. 25
The S855C/LS855C Shovel Logger is designed for log transferring, loading, and shovel logging (hoechucking) by swinging logs closer to the road side minimizing ground surface impact and damage.
| Serial | 1. Publication: Issue 2.1, February 2012, 2. Publication: Issue 1.1, July 2015 |
|---|
